cotton seeds oil refining machine for crude vegetable oil

Sunflower oil production line basic flow chart:oilseeds pretreatment→pre-pressing→Solvent extraction→oil refining.Our engineer can design different process of sunflower oil extraction machinery, according to the different requirements and target price.

Leader Edible Oil Refining Processes Co., LTDcan configure design process sunflower seed oil extraction production line for the customer, under normal circuLDtances, process engineers will configure the latest technoloLD to customers depending on customer requirements and target price.

Specifications

cotton seeds oil refining machine
1.first grade edible oil
2.Used for all kinds seeds,peanut ,sesame,soybean...

Edible cotton seed oil refining machine for crude soybean oil

1.Introduction

Continuous Oil Refining Process Introduction

Alkali hot water

Crude oil→filter→mix→reactor→mix→reactor→centrifugal separation→oil residue

↑ ↓

Phosphoric acid hot water→mix ↓

↓

degumming oil←cooler←dry←centrifuge separation←mix←alkali liquor

↓ ↓

↓ vacuum steam jet pump←steam citric acid

↓ ↓

bleaching earth→mix→decoloring→filter→decoloring oil→mix→heat

↓

refined oil←filter←cool←deodorizing←vacuum

2.Working process

(1)Pump crude oil into refining tank and heat with conduction oil, and the temperature will reach about 70°C-80°C after one hour. Add acid or alkali to separate according to the acid value. After one hour's processing and 4-6 hours deposit, then convey soap stock to storage tank.

(2)Pump refined oil into decoloring tank. When it is up to 90-110°c after one hour's heating,

add clay into tank for 20min's processing. Then separate clay and oil with filter.

(3)Put discolored oil into deodorization tank with vacuum pump. Heat and process with steam for odor removal.

After filtering, you will get final oil product.

3.Functions of main parts

(1) Refining section: used to P-acid de-gumming, alkali refining de-acid and water rinsing.

(2) Decoloring section: used to remove off pigments, bleaching oils and grease dehydrate.

(3) Deodorizing section: to remove off the odor components in oil.

(4) Dewax: used to remove off the wax in the oil, in order to get the high quality oil.

(5) Heat-transfer oil stove: supply each device production needing heat enerLD, temperature reach above 280°C.

(6) Steam generator: produce the needing steam for de-odoring and distillation.

(7) Vacuum pump: supply needing vacuum for dehydrate, de-color, de-odor. Vacuum degree can reach above 755mm Hg.

(8) Press filter: filter clay, filter out clear oil.

(9) Air compressor: blow dry bleached clay, blow empty the leftover oil in the press filter.

4.Professional Advice

Please kindly inform us your required daily capacity, treated quantity, raw material, covering space and related data,

so that we can make flow chart production line for you as your requirement. we will stand at your point to suggest low cost and suitable production line for you.

Sincerely want to cooperate with you.

Besides refining equipment, our company also provide high quality prepressing equipment and leaching/extraction equipment with

which the you can prepress the raw material and get the oil in the cake.

Welcome to contact us.

Any other questions ,pls contact me without hesitation .

Leader Edible Oil Refining Processes Co., LTD supply the complete set of Cooking oil production line machinery including sunflower oil production line, palm oil production line, soya bean oil production line, peanut oil production line, cotton seeds oil production line, maize corn germ oil production line, clamelia oil production line, rapeseeds oil production line, canola oil production line, coconut cropra oil production line, shea oil production line, groundnuts oil line, sesame oil production line,black seeds oil production line, jatropha seeds oil production line,moringa seeds oil production line.
